VCM-5D Comparison Microscope

VCM-5D Comparison Microscope VCM-5D Comparison Microscope

Product name:VCM-5D Comparison Microscope

Item:

Details:

VCM-5D Forensic Comparison Microscope




Specification:

*Optic magnification range: 2.5X-120X
*Eyepiece: WF10X /Φ 22mm, WF20X /Φ 14mm
*Objective: 0.6X, 1.2X, 2X, 3.5X, 5X(0.3X, 2.0X optional)
*Objective view field diameter: Φ2.5mm~Φ90mm
*Built-in digital system: 3mega pixels, 1024X768 resolution, support USB numerical or VGA/AV/DAI output
*Working distance: 100mm
*Objective stage dimension: 100mm, moving range: X/50mm Y/50mm Z/50mm
*Objective stage horizontal linkage range: 50mm
*Coarse moving range: 50mm
*New semiconductor light source illumination (brightness adjustable)
*Illumination: 300W independent exteriorized cold light source, Photoconductive fiber with adjustable condenser
*Power Supply: 220V AV input, 24V DV stable voltage output, Accords with International safe standard

Standard accessory:

*Dust cover---1pc
*Instruction manual in English --- 1pc
